Addition curing silicone25



Product Description

Product Overview

The EPS Component Molding industry demands mold-making materials that deliver exceptional precision, reliability, and cost-efficiency. Whether you are producing decorative architectural elements, artisan crafts, food-grade products, or industrial components, the quality of your silicone mold directly determines the quality of every cast you produce.

Hong Ye Silicone's Addition Curing Silicone rubber (Model HY-E620) has been specifically formulated to excel in EPS & foam decoration applications. Based on advanced platinum-catalyzed technology, this Liquid silicone rubber delivers near-zero shrinkage, outstanding tear resistance, and food-safe curing — properties that set it apart from conventional condensation-cure systems.

With 20 Shore A hardness, this formulation strikes the optimal balance between flexibility for easy demolding and rigidity for dimensional stability. The viscosity range of 16000-20000 cps ensures excellent flow properties that capture every surface detail while minimizing air entrapment during pouring.

Manufactured in our 10,000 sqm facility in Shenzhen with 20 automated production lines, every batch undergoes rigorous quality control to ensure consistent performance. With over 25 years of silicone R&D experience and exports to 138+ countries, Hong Ye Silicone is the trusted partner for mold makers worldwide.

Key Features

• Addition Curing (Platinum Catalyst) System — Unlike tin-catalyzed condensation cure silicones, our platinum system produces no byproducts during curing. This means zero shrinkage (<0.1%), no odor, no toxic emissions, and complete safety for food-contact and skin-contact applications.

• Near-Zero Shrinkage (<0.1%) — Every detail captured in your master pattern is faithfully reproduced in every single cast, even after hundreds of production cycles.

• High Tear Strength (20 kN/m) — Mold edges, thin sections, and detailed areas resist splitting and tearing during demolding.

• Excellent Flow & Detail Reproduction — At 16000-20000 cps viscosity, the material flows readily into fine textures, sharp corners, and complex undercuts.

• Wide Temperature Stability (-60°C to 200°C) — Perform reliably in any production environment.

• Flexible Mixing Ratios (1:1 or 10:1 by weight) — Choose 1:1 ratio for extended working time. Switch to 10:1 for faster turnaround.

• Food-Grade & Skin-Safe Certification — Fully compliant with FDA, REACH, and RoHS standards.

• Extended Mold Life (800-1000+ casts) — With proper maintenance, a single mold can produce hundreds to over a thousand casts.

• Chemical Resistance — Fully compatible with gypsum, cement, GRC, polyurethane foam, epoxy resin, wax, concrete, polyester resin.

Technical Specifications

Parameter	Specification	Test Standard
Model	HY-E620	—
Appearance	Translucent liquid	Visual
Hardness	20 Shore A	GB/T 531
Viscosity	16000-20000 cps	GB/T 10247
Tear Strength	≥20 kN/m	GB/T 529
Tensile Strength	≥5.0 MPa	GB/T 528
Elongation at Break	≥400%	GB/T 528
Shrinkage Rate	≤0.1%	Enterprise standard
Mixing Ratio	1:1 or 10:1 (by weight)	—
Pot Life (25°C)	35-50 minutes	—

Detailed Applications

1. EPS Component Molding
EPS decorative molding, exterior insulation panels, and foam shapes. The 20A hardness provides the ideal combination of flow and strength for EPS & foam decoration work.

2. Compatible Casting Materials
Gypsum/plaster, cement and GRC mixtures, polyurethane foam, epoxy resin, polyester resin, wax, concrete, and low-melt alloys.

3. Small-Batch Prototyping
With MOQ as low as 2kg, ideal for prototype development and design validation.

4. High-Volume Production
Scale up to full production. Batch-to-batch consistency guaranteed by ISO 9001 quality system.

5. Custom Color Matching
Custom colors can be formulated for color-coding molds by hardness, application, or production line.

6. Educational & Training Use
Forgiving working characteristics make it an excellent choice for training new mold makers.

Operating Guide

Step 1 — Pattern Preparation
Clean master pattern. For porous originals, apply 2-3 coats of shellac or PVA sealer. For non-porous patterns, apply petroleum jelly or release agent.

Step 2 — Mold Box Construction
Build rigid containment box with 3-5cm clearance on all sides. Seal all joints to prevent leaks.

Step 3 — Weighing & Mixing
Weigh Part A and Part B according to chosen ratio (1:1 or 10:1). Stir gently but thoroughly in ONE direction for 3-5 minutes.

Step 4 — Vacuum Degassing
Pull vacuum to -0.095 MPa. Hold for 2-3 minutes until bubbling stops.

Step 5 — Pouring
Pour in thin, steady stream from lowest point. Allow silicone to flow naturally.

Step 6 — Curing
Allow 4-5 hours at 25°C. For faster turnaround, cure at 60°C for 2 hours.

Step 7 — Demolding & Inspection
Carefully separate mold from pattern. Inspect for bubbles or defects.

Step 8 — Post-Cure & First Use
Allow 12-24 hours rest before first production use.

Packaging & Shipping

• Available Sizes: 1kg, 5kg, 20kg, 25kg, and 200kg packages
• Storage: Cool, dry place (5-30°C) in original sealed containers
• Shelf Life: 12 months
• Delivery Time: 3-7 working days for standard orders
