Product Description

Product Attributes

Model No.: HY-9400/HY-9405

Brand: HONG YE SILICONE

Origin: HUIZHOU

Certification: 9001

Packaging & Delivery

Selling Units	:	Kilogram
Package Type	:	1kg/5kg/25kg/200kg
Picture Example	:

The file is encrypted. Please fill in the following information to continue accessing it

Liquid Tank Adhesive



Product Description

HONG YE SILICONE’s Electronic Potting Silicone is a high-performance two-component RTV 2 Silicone Rubber , also known as Electronic Potting Compound, Silicone Potting Compound and Thermally Conductive Potting Compound. Made of high-purity Silicone raw materials with Platinum cured mold silicone technology, this Addition Curing Silicone offers superior insulation and high-temperature resistance, outperforming Condensation Curing Silicone Mold Rubber. It meets the quality standards of our Industrial mold silicone rubber and Pad Printing Silicone , providing reliable protection for high-end electronics and high-temperature equipment.

Product Overview

Our Electronic Potting Silicone, also called Liquid Tank Silicone and Silicone Encapsulant , is a high-performance encapsulant for high-end applications. Transparent Part A and blue Part B (color customizable) form a two-component system with excellent insulation, high-temperature resistance and moisture-proof performance. Consistent with our Industrial Mold Silicone rubber in quality, it is ideal for high-end electronic circuit boards, power modules, high-temperature ovens and induction cookers that require strict protection.

Technical Specifications

Mixing ratio (A:B): 1:1 (weight); Degassing: 0.08MPa for 3 minutes; Curing time: 3-8h (25℃), 20min (80-100℃); Storage life: 1 year (sealed); Packaging: 1,5,20,25,200KG/barrel; Transportation: Non-hazardous; Compatibility: Aluminum, galvanized plate, stainless steel, PC, PP, ABS, PVC; Insulation: Meets high-end electronic industry standards; High-temperature resistance: Stable in high-temperature equipment.

Product Features

Superior insulation performance prevents short circuits and leakage, ensuring safe operation of high-end electronics. Excellent high-temperature resistance maintains stability without deformation or oil seepage in high-temperature environments. Platinum cured mold silicone technology ensures stable performance, better than Condensation curing silicone mold rubber. Low viscosity enables easy pouring into complex components; dual curing modes offer flexibility. High toughness absorbs thermal stress without cracking; excellent sealing and moisture-proof performance extend product service life.

How to Use

1. Stir Part A and Part B separately to ensure uniform insulation and high-temperature performance.

2. Mix A and B at 1:1 weight ratio, stirring thoroughly for 2-3 minutes.

3. Degas at 0.08MPa for 3 minutes, then pour gently into high-end components or high-temperature equipment slots.

4. Cure at 25℃ for 3-8h; heating curing (80-100℃, 20min) enhances high-temperature resistance.

Application Scenarios

Widely used for high-end electronic circuit boards, power modules, optical electronics, LCD manufacturing, high-temperature ovens, induction cookers and high-temperature air filters. As a Thermally Conductive Potting Compound , it improves product durability and safety, helping buyers gain competitiveness in high-end markets.

Certifications and Compliance

Certified by ISO9001, CE, RoHS and UL, complying with high-end electronic and high-temperature equipment industry standards, ensuring global market access.

Customization Options

Formula can be customized to enhance insulation or high-temperature resistance; Part B color and packaging are adjustable, same as our Industrial mold silicone rubber customization services.

Production Process

Strict quality control includes insulation and high-temperature performance testing. High-purity Silicone raw materials and advanced mixing technology ensure product reliability, same as our Pad printing silicone production standards.

FAQ

Q: What’s its high-temperature resistance?

A: It is stable in high-temperature equipment like ovens and induction cookers.

Q: Is it suitable for high-end electronics?

A: Yes, its superior insulation ensures safe operation.

Q: Can the formula be customized for better insulation?

A: Yes, we offer formula optimization for specific needs.
