Self Healing Jelly Gel Extends HEPA Filter Service Life

This article provides a technical analysis of self healing jelly gel extends HEPA filter service life, covering material properties, installation procedures, key performance parameters, and quality assurance to support engineering and procurement decisions.

1  Introduction

Self-healing tank gel filter replacement. Hong Ye HY-9400 has become a benchmark grade for sites where filters are replaced several times a year without reapplying sealant. The permanently tacky gel reflows around the knife edge within minutes, restoring an airtight seal without adding new material. As a two-component addition-cure platinum jelly gel mixed 1:1 by weight, HY-9400 offers a viscosity of 1200+/-300 mPa.s, 20 to 40 minute operation time and 4 to 6 hour room temperature cure. It self-levels after pouring without vacuum degassing, and cures into a permanently soft, tacky, jelly-like mass that remains serviceable across a temperature range of -60 to 200 degrees Celsius. The cured gel resists ozone, UV, moisture, salt spray and common cleanroom disinfectants, with linear shrinkage below 0.1 percent and dielectric strength above 20 kV/mm.

This technical analysis examines the material properties, installation methodology and field performance of HY-9400 blue jelly gel as used in this application area. Engineers and procurement managers will find actionable data on viscosity, cure schedule, penetration and chemical compatibility to support specification decisions.

2  Product Requirements

In this application, the gel sealant must meet the following requirements:

• Permanent tack and self-healing: remain soft and adhesive throughout service life, re-sealing after module replacement without re-pouring.

• Self-leveling viscosity of 1200-2000 mPa·s allows the gel to flow into narrow channels and corners without vacuum assistance.

• Wide service temperature range of -60°C to 200°C ensures reliable performance in outdoor and industrial environments.

• Low shrinkage below 0.1% with no condensation by-products eliminates voids, odor and corrosion risks.

• Strong electrical insulation: dielectric strength above 20 kV/mm and volume resistivity above 10^14 Ω·cm.

• Chemical resistance against ozone, UV radiation, moisture, salt spray and common disinfectants.

• Regulatory compliance: RoHS 2.0 and REACH SVHC as baseline; FDA 21 CFR 177.2600 and LFGB available for food-grade or skin-contact grades.

3  How Hong Ye Jelly Gel Solves the Problem

Hong Ye HY-9400 addresses these requirements through a combination of material formulation design and application engineering support. To obtain consistent results, engineers should observe four operating rules. First, always stir component B thoroughly for at least two minutes before dispensing, because the color paste and platinum catalyst tend to settle during storage. Second, weigh A and B accurately at 1:1 by weight using a calibrated digital scale; off-ratio mixing causes soft or sticky spots. Third, use clean polyethylene, nylon or nitrile gloves and dedicated tools; natural rubber latex, sulfur-cured rubber, amines, phosphorus compounds and tin-cured silicone will inhibit the platinum catalyst. Fourth, pour at 18 to 35 degrees Celsius and allow 4 to 6 hours before putting the assembly into service; for mass production, 60 to 80 degree heat curing can shorten the cycle to 30 to 60 minutes.

Beyond standard operating procedures, Hong Ye provides on-site pouring guidance, custom formulation for volume projects and batch-to-batch Certificate of Analysis verification. The three key success factors in this application are: (1) selecting the correct viscosity and penetration grade for the channel geometry, (2) enforcing strict 1:1 ratio and clean-tool discipline to prevent platinum inhibition, and (3) maintaining the recommended 18-35°C pour temperature. When these conditions are met, field data consistently shows zero leakage over five or more years of service.

4  Corresponding Product Model Parameters

HY-9400 — blue, high tack

  Appearance: blue soft jelly gel

  Cone Penetration: 200±20 (1/10 mm)

  Viscosity (A/B mixed): 1200±300 mPa·s

  Mixing Ratio: Part A : Part B = 1 : 1 by weight

  Working Time: 20-40 min at 25°C

  Cure Time (RT): 4-6 h at 25°C

  Heat Cure: 30-60 min at 60-80°C

  Hardness / Feel: cone penetration 200 (very soft)

  Density: 0.97 g/cm³

  Linear Shrinkage: <0.1%

  Service Temperature: -60°C to 200°C

  Dielectric Strength: >20 kV/mm

4.2  Grade Selection Guide

• HY-9400 (blue, cone penetration 200): highest tack and softness; the standard choice for HEPA filter gel channels, biosafety cabinet seals and any application requiring maximum adhesion and re-sealability.

• HY-9405 (blue, cone penetration 170): medium tack and firmness; suitable for electronic potting, sensor encapsulation and applications requiring a balance of softness and dimensional stability.

• HY-9409 (transparent, cone penetration 150): lowest tack and firmest feel; preferred for transparent gel pads, intimate apparel, prosthetic devices and applications requiring visual clarity or easy repositioning.

5  General Technical Parameters

  Product Type: Two-component addition-cure platinum-catalyzed silicone jelly gel (RTV-2)

  Mixing Ratio: Part A : Part B = 1 : 1 by weight

  Cure System: Platinum addition cure, no condensation by-products

  Viscosity (mixed): 1200-2000 mPa·s depending on grade

  Cone Penetration: 150-200 (1/10 mm)

  Working Time: 20-40 minutes at 25°C

  Cure Time: 4-6 h at 25°C; 30-60 min at 60-80°C

  Operating Temp: 18-35°C recommended for pouring

  Service Temp: -60°C to 200°C continuous

  Linear Shrinkage: <0.1%

  Dielectric Strength: >20 kV/mm

  Volume Resistivity: >1×10^14 Ω·cm

  Thermal Conductivity: 0.18-0.22 W/(m·K)

  Self-Leveling: Yes, no vacuum degassing required

  Self-Healing: Yes

  Shelf Life: 12 months sealed below 25°C

  Packaging: 1kg, 5kg, 20kg, 25kg, 200kg kits (A+B)

6  Manufacturing Process

6.1  Surface Preparation

Clean all contact surfaces with isopropyl alcohol or acetone to remove grease and dust. Ensure surfaces are completely dry before pouring.

6.2  Component B Stirring

Stir Component B thoroughly for at least 2 minutes before each use. Color paste and platinum catalyst may settle during storage.

6.3  Weighing

Weigh A and B at 1:1 by weight on a calibrated digital scale, accuracy within ±2%.

6.4  Mixing

Mix slowly and thoroughly for 2-3 minutes, scraping sides and bottom. Avoid high-speed mixing that entraps air.

6.5  Degassing (Optional)

HY-94 is self-leveling; vacuum degassing generally not required. For optical/electronic critical use, degas at -0.08 MPa for 3-5 min.

6.6  Pouring

Pour slowly along one end, maintaining 5-10 cm height above surface. Ambient temp 18-35°C.

6.7  Curing

4-6 h at 25°C, or 30-60 min at 60-80°C. Do not disturb until fully cured.

6.8  Inspection

Check uniform color, complete fill, no sticky areas. Properly cured gel is smooth, glossy and uniformly soft.

6.9  Cleanup

Clean tools with isopropyl alcohol before cure. Cured gel is removed mechanically. Wear PE/nylon/nitrile gloves; avoid natural latex.

7  Frequently Asked Questions

Q: Why is my cured gel sticky or soft in some areas?

A: Usually inaccurate 1:1 ratio, insufficient mixing, or unstirred Component B. Sulfur/tin/amine/phosphorus contamination inhibits platinum cure. Use clean dedicated tools.

Q: Can I cure faster with heat?

A: Yes, 30-60 min at 60-80°C. Do not exceed 100°C to avoid surface skinning and trapped bubbles.

Q: Is vacuum degassing needed?

A: Generally no. HY-94 self-levels and self-degasses. Only optical or high-voltage electronic applications may require vacuum.

Q: What is the shelf life?

A: 12 months sealed below 25°C away from sunlight. Reseal after opening and use within 3 months. Always stir B before use.

Q: Is it safe for skin contact?

A: HY-9400 and HY-9405 can meet FDA 21 CFR 177.2600 and LFGB requirements on request. Standard grades meet RoHS 2.0 and REACH SVHC.

Q: What is the coverage of a 20kg kit?

A: Approximately 60-100 standard 610×610mm HEPA modules. Formula: channel length × width × depth × 0.97 g/cm³.

Q: Can cured gel be repaired?

A: Yes. HY-94 self-heals after minor displacement. For major repairs, remove contaminated gel, clean with isopropyl alcohol and re-pour fresh gel.

8  Quality Assurance & Certification

• ISO 9001 certified manufacturing facility in Shenzhen with 20,000 square meters of production area.

• Monthly addition-cure silicone capacity exceeding 500 tons, ensuring stable supply for volume orders.

• Every batch is released with a Certificate of Analysis covering viscosity, cone penetration, cure time, color and tack.

• Documented quality control procedures span incoming raw material inspection, in-process monitoring and finished-product testing.

• Technical team with an average of 10 or more years of silicone industry experience provides formulation and troubleshooting support.

• Custom formulation, color matching and private-label or neutral packaging are available for volume customers.

8.2  Certifications & Compliance Documents

• RoHS 2.0 — restriction of hazardous substances in electrical and electronic equipment.

• REACH SVHC — EU chemicals regulation compliance.

• ISO 9001:2015 — quality management system certification.

• FDA 21 CFR 177.2600 — available on request for food-contact and skin-contact grades.

• LFGB — available on request for food-grade applications in the European market.

• MSDS/SDS — safety data sheet provided with every shipment.

9  Conclusion

Hong Ye HY-9400 blue jelly gel provides a technically proven, field-validated sealing solution for this application. Its self-leveling viscosity, 20-40 minute working time, 4-6 hour room-temperature cure, shrinkage below 0.1% and wide -60°C to 200°C service range make it suitable for the most demanding sealing and potting requirements. Proper surface preparation, thorough B-component stirring before each use and accurate 1:1 weight-ratio mixing are the three factors that determine success; when these are followed, the gel delivers multi-year zero-leakage performance with minimal maintenance.

For product samples, pricing, TDS, MSDS or application engineering support, contact Hong Ye Jie Technology Co., Ltd.
