HONG YE SILICONE Electronic Potting Compound (flame-retardant silicone) is a professional Silicone Encapsulant designed for oil drilling equipment. As a two-component Addition Curing Silicone with 1:1 mixing ratio, it cures without heat release, corrosion or high shrinkage. Featuring excellent flame retardancy, insulation, waterproofing and temperature resistance, it protects electronic components in harsh oil drilling environments. Customizable hardness, viscosity and operation time, it meets strict industrial standards, bringing safety and cost-saving value to global oil drilling clients.
Product Overview
Our Electronic Potting Compound, also called Silicone Potting Compound or Flame-Retardant Silicone, is a high-performance two-component liquid silicone specially developed for oil drilling equipment. With A:B=1:1 weight ratio, it cures into a stable elastomer after mixing, providing comprehensive sealing and protection for electronic components in oil drilling systems. As an experienced RTV 2 Silicone Rubber manufacturer, HONG YE SILICONE integrates R&D and production, ensuring this potting compound adapts to high-pressure, high-humidity and flammable oil drilling environments. Technical Specifications
Model HY-9045 (addition curing silicone): 1:1 mixing ratio; liquid appearance for both A and B components; viscosity 2500±500 Pa.s; hardness 45±5 A°; operation time 30-60 minutes (25℃); curing time 4-5 hours (80℃); dielectric strength ≥25 kv/m-1; dielectric constant 3.0 (1.2MHz); volume resistance ≥1×1015 Ω. Other models and custom parameters are available based on requirements.
Product Features & Advantages
- Two-component (1:1 ratio) addition curing silicone, cures without heat release, corrosion and low shrinkage. - Excellent flame retardancy and insulation, critical for safe operation in flammable oil drilling environments. - Waterproof, moisture-proof, mildew-proof and dust-proof, adapting to harsh oil drilling working conditions. - Maintains elasticity in a wide temperature range, with strong weather and chemical medium resistance. - Superior to ordinary Electronic potting compound, with good yellowing resistance and long service life. - Strict quality control, produced by our factory with 20 production lines, ensuring stable batch consistency. - Low volatility and strong adhesion, suitable for various oil drilling electronic components.
How to Use
1. Fully stir A and B components separately in their own containers before mixing. 2. Mix A and B in a 1:1 weight ratio, ensuring uniform stirring. 3. Degas the mixed silicone at 0.08MPa for 3 minutes after mixing. 4. Cure at room temperature or by heating; low temperature in winter can properly heat to accelerate curing.
Application Scenarios
This Electronic Potting Compound is widely used in oil drilling equipment, including oil drilling power modules, PCB substrates, electronic control modules, sensors and outdoor drilling signal equipment. It effectively seals and protects electronic components from high pressure, humidity and flammable hazards, reducing failure rates, extending equipment service life and lowering maintenance costs for oil drilling clients.
Customization Options
We provide flexible customization services, including adjusting hardness, viscosity, operation time and curing speed according to customer needs. We also customize special formulas for oil drilling high-pressure, high-temperature scenarios, supporting OEM services. As a professional manufacturer, we can meet various personalized needs of global采购商s.
Certifications & Compliance
Our Electronic Potting Compound complies with international industrial standards, supported by our factory’s ISO9001, CE and UL certifications. With 91%-100% export rate, our products are sold to global oil drilling markets, meeting strict quality and safety requirements.
FAQ
Q: Is this potting compound suitable for high-pressure oil drilling environments? A: Yes, it has excellent pressure resistance and sealing performance, perfectly adapting to high-pressure oil drilling working conditions. Q: What mixing ratio does it require? A: The standard ratio is A:B=1:1 (weight ratio), which is easy to operate and ensures stable curing effect. Q: Are there any substances that affect its curing? A: Avoid contact with organotin compounds, sulfur, amines, incompletely cured condensation silicone and other substances, which will affect curing. Q: What is the storage period and transportation method? A: Storage period is 1 year (below 25℃); it is non-dangerous goods and can be transported as general chemicals.
