Product Summary
HONG YE SILICONE’s Foamed Silicone Rubber Tube is a high-performance 2-component Addition Curing Silicone product, specifically designed for fluid conveying and protective scenarios. It features excellent flexibility (bending radius ≤5× tube outer diameter), high pressure resistance (working pressure up to 1.2MPa), and a seamless integral structure, with fine uniform closed-cell foam inside. The tube is non-toxic, odorless, resistant to high and low temperatures (-65℃-200℃), easy to install and cut, passed SGS and RoHS certifications, compatible with our Industrial mold silicone rubber and Liquid Tank Silicone, serving B2B buyers in automotive, industrial, and electronic fluid conveying fields.
Product Overview
HONG YE SILICONE’s Foamed Silicone Rubber Tube is a professional tubular foamed silicone product, integrating flexibility, pressure resistance and sealing performance, designed to solve the pain points of traditional rubber tubes (poor flexibility, easy leakage, weak pressure resistance) in fluid conveying and component protection. As a 2-component addition curing product, it is formed by precision extrusion and foaming, with a seamless outer surface and uniform closed-cell foam inner layer—ensuring no fluid leakage, good thermal insulation and sound insulation, while maintaining ultra-high flexibility that allows bending and twisting without cracking or deformation. Made of high-purity Silicone raw materials, it is non-toxic, odorless, and free of harmful substances, adapting to various harsh working environments. Compatible with most of our core silicone products, it provides a one-stop solution for B2B buyers in fluid conveying, heat insulation, and component protection scenarios.
Technical Specifications
Type: 2-component addition curing foamed silicone rubber tube
Structure: Seamless integral structure, closed-cell foam inner layer, smooth outer surface
Flexibility: Bending radius ≤5× tube outer diameter, can be bent and twisted repeatedly without damage
Pressure Resistance: Working pressure up to 1.2MPa, burst pressure ≥3.6MPa, no leakage under rated pressure
Temperature Range: -65℃ to 200℃ (long-term use), 250℃ (short-term use)
Foam Density: 0.3-0.6 g/cm³, fine uniform pores (40-80μm)
Color: Transparent, white, black (customizable with food-grade/industrial-grade pigments)
Size Range: Inner diameter 3-50mm, outer diameter 6-60mm, wall thickness 1.5-5mm (customizable)
Mixing Ratio: 1:1 (Part A:Part B, by weight) for raw material preparation
Cure Method: High-temperature extrusion curing (120℃-150℃), rapid forming
Certifications: SGS eco-toxicity, RoHS, FDA compliant (for food contact models)
Key Traits: High flexibility, pressure resistance, seamless leak-proof, closed-cell insulation, easy installation
Packaging: 5/10/20 meters per roll, moisture-proof plastic packaging; customized packaging available
Product Features & Advantages
1. Ultra-High Flexibility & Bendability: Bending radius as small as 5× the tube outer diameter, can be bent, twisted and routed freely in narrow spaces or complex equipment, no cracking, no deformation, solving the problem of traditional rubber tubes being stiff and difficult to install in confined areas.
2. High Pressure Resistance & Leak-Proof: Working pressure up to 1.2MPa, burst pressure 3 times the rated pressure, seamless integral structure and closed-cell foam inner layer effectively prevent fluid leakage, ensuring stable fluid conveying even in high-pressure working conditions.
3. Dual Insulation Performance: Closed-cell foam structure provides excellent thermal insulation and sound insulation—effectively isolating temperature changes to protect sensitive fluids, and reducing noise generated by fluid flow, suitable for high-temperature or low-temperature fluid conveying scenarios.
4. Durable & Environmentally Friendly: Made of high-purity addition curing silicone, non-toxic, odorless, no harmful substances, no pollution to conveyed fluids; excellent aging resistance, no brittle fracture, no performance degradation after long-term use (service life ≥5 years in normal working conditions).
5. Easy Installation & Customization: Lightweight, easy to cut to any length according to actual needs, no professional tools required; size (inner diameter, outer diameter, wall thickness), color, and foam density can be customized to adapt to different fluid conveying and installation requirements.
6. Wide Compatibility: Compatible with HONG YE SILICONE’s industrial Mold Silicone rubber (for tube fitting molding) and liquid tank silicone (for fluid storage matching), forming a complete fluid conveying solution, enabling one-stop procurement for B2B buyers.
How to Use
1. Preparation: According to the actual fluid conveying requirements, select the appropriate size of foamed silicone rubber tube, or customize the size with our technical team.
2. Cutting: Use ordinary cutting tools to cut the tube to the required length, ensuring the cut is flat and free of burrs (avoid affecting sealing performance when connecting fittings).
3. Installation: Insert the tube into the matching fittings (molded with our industrial mold silicone rubber), tighten the clamp appropriately to ensure a tight connection, no leakage; the tube can be bent and routed freely according to the equipment layout.
4. Maintenance: Regularly check the tube surface for damage, aging or leakage; avoid contact with sharp objects and strong corrosive substances (for corrosive fluid scenarios, select our customized anti-corrosion model); clean the tube inner wall regularly to ensure smooth fluid conveying.
Application Scenarios
Focus on fluid conveying and protective scenarios, widely used in: 1. Automotive industry: Engine cooling fluid conveying, air conditioning refrigerant tubes, battery cooling tube (paired with industrial mold silicone rubber); 2. Industrial equipment: High-temperature/low-temperature fluid conveying, equipment lubricating oil tubes, thermal insulation protective tubes (paired with high-temperature insulation silicone); 3. Electronic industry: Electronic component cooling fluid tubes, precision instrument fluid conveying (paired with Electronic Potting Compound); 4. Food industry: Edible oil, beverage conveying tubes (FDA compliant, paired with Food grade mold silicone); 5. Medical industry: Medical fluid conveying auxiliary tubes (medical grade model, ISO 10993 compliant, paired with Medical Grade Body Silicone); 6. Robot industry: Robot hydraulic fluid tubes, flexible protective tubes (paired with robot silicone). It helps B2B buyers improve fluid conveying efficiency, reduce leakage risks, and extend equipment service life.
Certifications and Compliance
Our Foamed Silicone Rubber Tube has passed SGS eco-toxicity testing, RoHS compliance certification, and FDA certification (for food contact models), medical grade models meet ISO 10993 biocompatibility standards. All products comply with international industrial standards, no harmful substances, no pollution, meeting the procurement requirements of B2B buyers in automotive, industrial, food, medical and other industries, facilitating export to global markets (EU, US, Southeast Asia, etc.).
Customization Options
We provide comprehensive customization services to meet different industry needs: 1. Size customization: Inner diameter (3-50mm), outer diameter (6-60mm), wall thickness (1.5-5mm) can be adjusted freely; 2. Performance customization: Pressure resistance (up to 2.0MPa), foam density (0.2-0.8 g/cm³), thermal insulation performance can be optimized according to requirements; 3. Color customization: Transparent, white, black, or other colors (food-grade/industrial-grade pigments); 4. Special models: Food-grade (FDA compliant), medical grade (ISO 10993 compliant), anti-corrosion, anti-static models can be customized according to specific scenarios.
Production Process
The production process of our Foamed Silicone Rubber Tube adheres to strict quality control standards: 1. Raw material preparation: High-purity addition curing silicone raw materials + foaming agent + functional additives (flexibility/pressure resistance modifiers) are mixed in a 1:1 ratio; 2. Precision extrusion: The mixed raw materials are extruded through a professional tubular mold to form a seamless blank; 3. High-temperature foaming & curing: The blank is sent to a high-temperature curing oven (120℃-150℃) for foaming and curing, ensuring uniform foam structure; 4. Quality inspection: Check the tube’s flexibility, pressure resistance, leakage, pore uniformity, and size accuracy; 5. Cutting & packaging: Cut the qualified tube into standard lengths, package with moisture-proof plastic, and label clearly.
FAQ
Q1: What is the maximum working pressure of the tube? A: The standard working pressure is up to 1.2MPa, and customized models can reach 2.0MPa, burst pressure is 3 times the rated pressure.
Q2: Can it be bent in narrow spaces? A: Yes, the bending radius is ≤5× the tube outer diameter, which can be freely bent and routed in narrow spaces without damage.
Q3: Is it suitable for food fluid conveying? A: Yes, we have FDA compliant food-grade models, non-toxic, odorless, no harmful substances, safe for edible fluid conveying.
Q4: Can the size be customized? A: Yes, inner diameter, outer diameter, wall thickness can be customized according to your specific needs, with a size range of inner diameter 3-50mm, outer diameter 6-60mm.
Q5: What is the service life of the tube? A: Under normal working conditions, the service life is ≥5 years, with excellent aging resistance and durability.
