Product Summary
HONG YE SILICONE’s Electronic Pad Printing Silicone is a premium two-component RTV 2 Silicone Rubber designed for high-precision electronic product printing. Featuring low viscosity, excellent fluidity and zero shrinkage, it delivers clear pattern transfer, exceptional wear resistance and oil/solvent resistance. Blended with DuPont for high-temperature stability, the product ensures consistent performance across fine textures, irregular patterns and logo printing on electronic components. Compatible with custom hardness adjustments (15A°-25A°), it integrates seamlessly with our Electronic Potting Compound and liquid silicone ecosystems, optimizing production efficiency for electronic manufacturers worldwide.
Product Overview
As a core offering in HONG YE SILICONE’s pad printing series, Electronic Pad Printing Silicone is a professional two-component (A/B) liquid silicone engineered for the electronics industry. It serves as the key material for manufacturing high-performance pad printing heads, enabling the transfer of patterns from steel plates to electronic products with precision. This product excels in printing irregular patterns, fine textures and logos on high-end electronic accessories, electronic toys and crafts—addressing the critical need for accuracy in electronic product customization. Made with premium Silicone raw materials, it boasts wear resistance, no deformation, no oil bleeding and superior ink transfer, making it a reliable choice for 15+ years of global exports to 138+ countries.
Product Features & Advantages
High-Precision Printing: Low viscosity and excellent fluidity ensure full mold filling, while zero shrinkage guarantees sharp, consistent pattern replication—ideal for fine electronic textures.
Durable Performance: Infused with DuPont , it offers high-temperature resistance (up to 200℃), wear resistance and oil/solvent resistance, extending pad service life and reducing replacement costs.
Superior Elasticity: Fine colloid texture with no impurities ensures strong rebound, enabling thousands of prints without deformation—enhancing production efficiency.
Easy Room-Temperature Curing: No special equipment required; curing time adjusts with hardener dosage (2%-3% of total weight), simplifying workflow and lowering energy consumption.
Eco-Friendly Compliance: Manufactured under ISO9001/CE/UL certifications, free of harmful substances, meeting global electronic industry environmental standards.
Technical Specifications
Form: Two-component (A/B) flowable liquid silicone
Curing Type: Room-temperature vulcanization (RTV)
Hardness Range: 15A°-25A° (customizable)
Viscosity: 5000-8000 mPa·s (25℃)
Curing Time: 3-4 hours (room temperature); adjustable via hardener ratio
Storage: 12 months shelf life (25℃, sealed, dry environment); avoid water contact
Packaging: 25kg/200kg iron drums (customizable)
How to Use (Step-by-Step)
Mold Preparation: Thoroughly clean the pad printing head mold with a degreaser, dry completely, and apply a thin layer of release agent for easy demolding.
Material Mixing: Blend the silicone base (Component A) with silicone oil (adjust ratio for desired hardness: 100:30 for soft pads, 100:10 for hard pads). Add 2%-3% curing agent (Component B) and stir vigorously for 2-3 minutes.
Defoaming: Place the mixture in a vacuum chamber for 5-10 minutes to remove air bubbles—critical for avoiding printing defects.
Casting & Curing: Pour the bubble-free mixture into the mold slowly, cover with a plate, and cure at room temperature for 3-4 hours before demolding.
Optimal Usage: Select pad size/hardness based on pattern dimensions (soft pads for fine patterns, hard pads for large/bold designs) to maximize printing quality.
Application Scenarios
This product is tailored for the electronics industry, widely used in:
High-end precision electronic accessories (e.g., phone cases, keyboard buttons)
Electronic toys (printing patterns/logos on plastic components)
Craft gifts (customized designs on electronic souvenirs)
Irregular-shaped electronic products (adapting to curved/special surfaces)
Logo silk-screening on electronic device housings
It helps electronics manufacturers achieve high-quality customization, reduce production errors, and meet the demands of premium product lines—ultimately enhancing market competitiveness.
Certifications and Compliance
Our Electronic Pad Printing Silicone adheres to international standards, with certifications including ISO9001, CE and UL. Like our Thermally Conductive Potting Compound and medical-grade silicones, it passes ROHS/SGS testing, ensuring compatibility with global electronic product safety regulations. This compliance eliminates export barriers and builds trust with overseas buyers.
Customization Options
We offer flexible customization to meet diverse production needs:
Hardness Adjustment: 15A°-25A° for soft/bold pattern requirements
Viscosity Modification: Tailored for specific mold complexity
Packaging Solutions: Smaller/larger drum sizes based on order volume
Formula Optimization: Customized for special inks or extreme environments (e.g., high humidity)
FAQ
Q: Can this silicone be used with different electronic inks?
A: Yes, it is compatible with most solvent-based and UV-curable electronic inks; our R&D team can optimize the formula for specific ink types.
Q: How does pad hardness affect printing results?
A: Soft pads (15A°-20A°) work best for fine patterns; hard pads (20A°-25A°) suit large/bold designs—reducing image distortion.
Q: What is the shelf life after opening?
A: Use within 1 month of opening; seal tightly after use to prevent moisture absorption.
Q: Can it be used with other HONG YE SILICONE products?
A: Yes, it pairs seamlessly with our Electronic Potting Compound for comprehensive electronic product assembly solutions. Q: What is the minimum order quantity (MOQ) for customization?
A: MOQ for customized hardness/packaging is 25kg; contact our team for bulk order discounts.
