Product Summary
HONG YE SILICONE’s Liquid Foamed Silicone is a ceramicization flame-retardant and ultra-high temperature resistant 2-component Addition Curing Silicone, featuring excellent ceramicization flame retardancy (ceramicization at 500℃, forming a hard protective shell), ultra-high temperature resistance (long-term use at 300℃, transient resistance at 1600℃), non-toxic fumes, suitable for ultra-high temperature and fire-safe scenarios. It has fine uniform closed-cell pores, 1:1 easy operation, passed SGS ceramicization flame retardancy certification, UL94 V-0 grade, compatible with high-temperature insulation silicone and Industrial mold silicone rubber, serving B2B buyers in aerospace, high-temperature industrial and fire protection industries.
Product Overview
HONG YE SILICONE’s Liquid Foamed Silicone (Foaming Silicone Rubber, Silicone Foam ) is a ceramicization flame-retardant ultra-high temperature resistant core product, specially developed for ultra-high temperature, fire-safe and extreme environment scenarios. As a 2-component addition curing silicone, it is formed by chemical foaming of flowable Part A and Part B, formulated with ceramicization modifiers and high-temperature resistant raw materials, featuring ceramicization at 500℃ to form a hard protective shell, which can effectively isolate flame and high temperature, prevent fire spread. It has ultra-high temperature resistance (long-term use at 300℃, transient resistance at 1600℃), UL94 V-0 grade flame retardancy, fine uniform closed-cell structure, good elasticity and high-temperature stability, effectively solving the problem of traditional foaming materials’ poor high-temperature resistance and easy burning in extreme high-temperature scenarios. Compatible with most of our high-temperature and industrial products, it is ideal for ultra-high temperature components, fire-safe protection and aerospace thermal insulation scenarios.
Technical Specifications
Type: 2-component addition curing silicone
Ceramicization & High-Temperature Resistance: Ceramicization at 500℃ (forming a hard protective shell, compressive strength increased by 900% after ceramicization), ultra-high temperature resistance (long-term use at 300℃, transient resistance at 1600℃), flame retardancy UL94 V-0 grade, self-extinguishing within 5 seconds, no toxic fumes
Foaming Feature: Fine uniform closed-cell pores (20-60μm), ceramicization structure, no combustion spread, high-temperature resistance, no pore collapse under ultra-high temperature
Temperature Range: -65℃ to 300℃ (long-term use), transient temperature resistance up to 1600℃
Mixing Ratio: 1:1 (Part A:Part B, by weight)
Cure Method: Room-temperature or heated (80℃, 1h) vulcanization
Certifications: SGS eco-toxicity, RoHS, SGS ceramicization flame retardancy certification, UL94 V-0 certification
Key Traits: Ceramicization flame-retardant, ultra-high temperature resistant, ceramicization at 500℃, transient resistance at 1600℃
Packaging: Part A (20/25/200KG/barrel), Part B (20/25/200KG/barrel)
Product Features & Advantages
1. Excellent Ceramicization Flame Retardancy: Ceramicization at 500℃, forming a hard protective shell, UL94 V-0 grade flame retardancy, solving the problem of traditional foaming materials’ easy burning and fire spread in ultra-high temperature scenarios.
2. Ultra-High Temperature Resistance: Long-term use at 300℃, transient resistance at 1600℃, can withstand extreme high-temperature impact, suitable for aerospace and high-temperature industrial scenarios.
3. Ceramicization & Elasticity Balance: While maintaining ceramicization flame retardancy and ultra-high temperature resistance, it retains good elasticity at room temperature, no brittle fracture, balancing high-temperature protection and usability.
4. Compatibility with High-Temperature Products: Compatible with HONG YE SILICONE’s high-temperature insulation silicone and industrial Mold Silicone rubber, forming a complete ultra-high temperature protection solution, enabling one-stop procurement. 5. Easy Operation: 1:1 simple mixing ratio, good flowability, easy to process into ultra-high temperature components, no professional high-temperature operation skills required, improving production efficiency.
How to Use
1. Take Part A and Part B according to 1:1 weight ratio, stir separately to eliminate sediment, ensure no impurities (avoid affecting ceramicization and high-temperature resistance performance).
2. Mix and stir thoroughly for 3 minutes until homogeneous, vacuum degas to remove air bubbles (ensure ceramicization uniformity and closed-cell structure).
3. Pour the mixture into ultra-high temperature component mold (paired with high-temperature insulation silicone), foam and cure at room temperature or by heating.
4. After full curing, the product can be used in ultra-high temperature scenarios; when exposed to 500℃ flame, it ceramicizes to form a hard protective shell, effectively isolating flame and high temperature.
Application Scenarios
Focus on ultra-high temperature and fire-safe scenarios: Aerospace spacecraft thermal insulation layers (paired with high-precision mold silicone), high-temperature industrial furnace gaskets (paired with industrial mold silicone rubber), fire protection sealing components (paired with Liquid Tank Silicone), aircraft engine heat insulation parts (paired with high-temperature insulation silicone), and nuclear power plant fire-safe components (paired with Electronic Potting Compound). It helps ultra-high temperature industry buyers improve fire safety and adapt to extreme environment requirements.
Certifications and Compliance
Passed SGS eco-toxicity certification, RoHS compliant, SGS ceramicization flame retardancy certification, UL94 V-0 certification, excellent ceramicization flame retardancy and ultra-high temperature resistance, meeting the ultra-high temperature procurement requirements of B2B buyers in aerospace, high-temperature industrial and fire protection industries, facilitating export to global markets.
Customization Options
Customizable ceramicization temperature (400℃ for high-demand scenarios), high-temperature resistance level (long-term use at 350℃ for high-demand scenarios), foaming ratio and hardness, adapting to different ultra-high temperature and fire-safe requirements, helping buyers optimize high-temperature protection effect.
Production Process
Ceramicization-oriented production process: High-purity high-temperature resistant Silicone raw materials → formula optimization (add ceramicization modifiers) → precision mixing → ceramicization test → high-temperature resistance test → standardized curing → fire safety inspection → packaging. Strict ceramicization and high-temperature testing ensures product stable performance in extreme environments.
FAQ
Q1: At what temperature does it ceramicize? A: Ceramicization at 500℃, forming a hard protective shell, which can effectively isolate flame and high temperature.
Q2: What is the high-temperature resistance? A: Long-term use at 300℃, transient resistance at 1600℃, suitable for extreme high-temperature scenarios.
Q3: Is it suitable for aerospace? A: Yes, ideal for aerospace spacecraft thermal insulation layers and aircraft engine heat insulation parts, with excellent ultra-high temperature resistance.
Q4: Will it release toxic fumes when exposed to fire? A: No, ceramicization flame-retardant formula, no toxic fumes, safe and environmentally friendly in fire scenarios.
