HY-916 Ultra Soft Pad Printing Silicone for Large Curved Irregular Surface Low Hardness High Deformation

Hongye HY-916 is an ultra soft two component RTV Pad Printing Silicone developed by Shenzhen Hongyejie Technology Co., Ltd. for large curved and irregular products. With 16±2 Shore A hardness, it is the lowest hardness and strongest deformation model among four series, with elongation ≥400 percent, tensile strength ≥2.5MPa and tear strength ≥10kN/m. The rubber is soft with good elasticity, can fully deform and conform to various complex curved surfaces during pressing.

Many enterprises encounter problems when printing large curved surfaces, deep concave surfaces and irregular products. Standard hardness pads cannot fully conform to product surfaces, causing incomplete pattern transfer, blurred edges and partial missing print. HY-916 ultra soft model specifically solves this problem. The low hardness high deformation rubber can fully wrap large curved surfaces during pressing, making complete contact with product surface and ensuring complete pattern transfer. Ideal for spherical, oval, humanoid, animal shaped large curved toys, irregular gifts, craft products and cosmetic bottles with irregular surfaces. Multiple colors available including red, yellow, white and green four standard colors. Standard 100:2 mixing ratio, easy operation.

Key Features

• 16±2 Shore A hardness, lowest among four models, ultra soft rubber

• Elongation ≥400 percent, strongest deformation, fully conforms to complex curves

• Specially designed for large curved, deep concave and irregular surface printing

• Solves incomplete transfer caused by standard pads unable to conform to curves

• Tensile ≥2.5MPa, tear ≥10kN/m, soft but durable

• Ideal for spherical, humanoid, animal toys and irregular gifts crafts

• Multiple colors available, red yellow white green four standard colors

• Standard 100:2 mixing ratio, easy operation

Technical Specifications

表格

Model Color Hardness A Viscosity mPa.s Time min Cure h Tensile MPa Tear kN/m Elong % Ratio Density

HY-916 R/Y/W/G 16±2 10000 30-40 2-4 ≥2.5 ≥10 ≥400 100:2 1.10

HY-901 R/Y/W/G 23±2 12000 30-40 2-4 ≥3.0 ≥12 ≥300 100:2 1.12

HY-912 R/Y/W/G 25±2 13000 30-45 2-4 ≥3.5 ≥15 ≥350 100:2 1.13

HY-902 R/Y/W/G 28±2 15000 30-40 2-4 ≥4.0 ≥18 ≥320 100:2 1.15

Note: Above are typical values, actual parameters subject to each batch COA report. Test conditions: temperature 25±2°C, relative humidity 50±5%.

Application Scenarios

Large Curved Toy and Figurine Printing

Toy industry has many products with large curved surfaces, such as spherical toys, oval figurines, humanoid dolls, animal shaped toys etc. These products have large surface curvature and irregular shapes, standard hardness pads cannot fully conform, causing incomplete pattern transfer, blurred edges and partial missing print during printing, seriously affecting product appearance quality.

Hongye HY-916 ultra soft Pad Printing Silicone is specially designed for large curved toy and figurine printing. With 16A hardness and elongation ≥400 percent, the soft elastic rubber can fully deform and wrap large curved surfaces during pressing, making complete contact with toy surface and ensuring complete pattern transfer. Whether it is spherical toy surface, humanoid figurine face and body, or animal shaped irregular surface, HY-916 ultra soft pad conforms well with clear complete patterns and sharp edges. Multiple colors available, choose suitable pad color based on toy color and ink characteristics. It solves large curved toy printing difficulties and improves printing qualification rate and product quality.

Irregular Gifts and Crafts Printing

Gift and craft industry products have various shapes, many are irregular designs, such as irregular perfume bottles, cosmetic bottle bodies, craft ornaments, irregular promotional gifts etc. Surfaces are irregular with deep concave areas, protrusions and large curvature changes, standard pads difficult to conform, printing difficulty is high.

Hongye HY-916 ultra soft pad printing silicone performs excellently in irregular gifts and crafts printing. The low hardness high deformation rubber can adapt to various complex surfaces, fully reach into deep concave areas, conform around protrusions, and make uniform contact on surfaces with large curvature changes, ensuring complete pattern transfer. The rubber is soft but has sufficient elasticity, quickly recovers shape after pressing without affecting continuous printing. Uniform ink pickup and transfer, clear pattern reproduction, ideal for LOGO, pattern and text printing on various irregular gifts and crafts. Standard 100:2 mixing ratio, easy operation, suitable for small batch multi variety production characteristics of gift and craft industry.

Operating Instructions

Step 1 Pad Mold Preparation: Thoroughly clean the pad mold, wipe with alcohol and apply mold release agent evenly, leave 5 to 10 minutes to dry. Pay special attention to curved surface cleaning for large curved pad molds. Place mold on a level stable surface.

Step 2 Component A Preparation: Stir component A base rubber thoroughly for 1 to 2 minutes before pouring to ensure uniform color and filler distribution, scrape bucket walls and bottom. HY-916 has lower viscosity, stir at moderate speed to avoid excessive bubble entrainment.

Step 3 Weighing and Mixing: Accurately weigh A and B at 100:2 ratio by weight using electronic scale, within ±5 percent tolerance. Mix thoroughly for 3 to 5 minutes, scraping container walls and bottom to ensure complete uniform mixing. HY-916 rubber is softer, avoid over mixing which introduces bubbles.

Step 4 Pouring and Degassing: Slowly pour mixed silicone from one side of the mold, let it flow naturally to fill. Fill to about 80 percent. Use vacuum at negative 0.09MPa for 2 to 3 minutes if available, HY-916 lower viscosity makes degassing easier. Without vacuum, let sit 5 to 10 minutes for natural bubble release.

Step 5 Curing and Demolding: After degassing, cover the mold and cure at room temperature 25°C for 2 to 4 hours. For faster curing, heat at 60°C for 30 to 60 minutes, temperature not exceeding 100°C. HY-916 rubber is softer, be extra careful during demolding, gently remove to avoid tearing and deformation. Let rest 24 hours before use.

Step 6 Usage and Maintenance: Wipe pad surface with alcohol before use. Do several test prints first to condition the surface. For large curved product printing, adjust pressure and speed, moderate pressure ensures full pad conformity. Gently remove residual ink with clean nonwoven cloth or tape. Wrap with plastic film when not in use, store in cool dry place, avoid compression deformation.

Selection Guide

HY-901 Economy 23A: Entry level choice, easy operation and cost effective, ideal for beginners, small batch multi variety production, sampling and regular flat product production.

HY-902 High Wear 28A: Highest wear resistance and longest service life, ideal for mass continuous production, high frequency pressing, hard flat surface printing, stationery and tools industry.

HY-912 Eco Friendly 25A: Export oriented general purpose model, RoHS and REACH certified, multiple colors with stable batch quality, ideal for export toys, gifts, electronics, stationery requiring eco certification.

HY-916 Ultra Soft 16A: Ultra soft for large curved surfaces, lowest hardness with highest deformation, elongation ≥400 percent, fully conforms to large curved, deep concave and irregular surfaces, ideal for spherical, humanoid, animal shaped large curved toys and irregular gifts.

Recommended Application

Ultra soft low hardness pad printing head for large curved and irregular surface products

Quality and Compliance

Each batch of Hongye HY-916 is produced under ISO 9001 certified quality management system. Tested for viscosity, mixing ratio, curing time, hardness, tensile strength, tear strength, elongation, color and density before shipment. Each batch comes with COA report. Hongye Silicone has focused on liquid silicone since 2005, 20000 square meter Shenzhen factory producing over 500 tons monthly, supplied to over 60 countries. Shelf life 12 months sealed below 25°C.

Packaging Specifications

Standard packaging includes 1kg trial kit, 5kg kit, 20kg bucket, 25kg bucket and 200kg drum. Components A and B packed separately. Custom packaging and OEM service available for orders above 200kg. Each package labeled with product name, model, batch number, production date, expiry date, mixing ratio, net weight and safety information.

Competitive Advantages

Hongye HY-916 stands out with formulation technology, vertical integration and customer focused service. We own silicone polymer synthesis and compounding production lines, fully controlling raw material quality and batch consistency. Our 20000 square meter Shenzhen factory produces over 500 tons monthly, prices typically 30 to 50 percent lower than imported premium pad printing silicone with comparable performance. HY-916 ultra soft model specifically solves large curved surface printing difficulties with industry leading low hardness high deformation formula. Standard models in stock for 3 to 5 working day delivery. Technical sales engineers provide on site dispensing trial production, pad mold design review and custom formulation service. OEM customers enjoy private label, neutral packaging, multilingual COA and exclusive batch traceability.

Ordering and Logistics

To order Hongye HY-916, contact sales with model, quantity, color, destination country and shipping method. We accept T/T telegraphic transfer, PayPal for sample orders and Alibaba trade assurance orders. 1kg trial kit available for first time cooperation. Standard packaging shipped within 3 to 5 working days after payment. DHL, FedEx, UPS worldwide shipping, sea freight available for bulk cargo. Condensation cure pad printing silicone is non hazardous under most shipping regulations. Each shipment comes with commercial invoice, packing list, COA and SDS.

Technical Support and Custom Service

Hongye has a dedicated technical service team of silicone chemists and application engineers with average industry experience over 10 years. We provide full lifecycle support including model selection guidance, on site or remote dispensing trial production, pad mold design review, printing parameter optimization, failure analysis and continuous quality improvement. For large curved irregular product printing, we provide professional technical guidance including pad shape design, pressure parameter adjustment and printing speed optimization. For customers with special requirements, our R&D center can develop custom formulations including hardness adjustment 10 to 20 Shore A, Pantone color matching, curing speed adjustment etc. Custom development typically takes 7 to 14 working days from requirement confirmation to sample shipment.

Precautions

Use polyethylene, nylon or nitrile gloves, do not use natural latex gloves. Avoid contact with sulfur containing substances, amines, phosphorus compounds, tin cure silicone and PVC as these may inhibit cure. Use calibrated scale for accurate 100:2 weighing, mix thoroughly for 3 to 5 minutes. HY-916 rubber is softer, avoid forceful pulling or compression during demolding and use to prevent tearing and deformation. Heat curing temperature not exceeding 100°C. Maintain good ventilation. Component B has mild irritation, avoid direct contact with skin and eyes. Seal containers immediately after use.

Storage

Store in sealed containers below 25°C in dry ventilated area, avoid direct sunlight, keep away from sulfur containing substances, amines, food and strong chemicals. Shelf life 12 months from production date. Seal immediately after taking material. Refrigeration at 5 to 15°C extends shelf life, warm to room temperature before opening to avoid condensation. Store components A and B separately. HY-916 rubber is softer, avoid heavy object compression during storage to prevent pad deformation. Store away from fire and heat sources with good ventilation.

FAQ

Q: Will HY-916 ultra soft pad be too soft causing pattern deformation?

A: No. HY-916 at 16 Shore A is the lowest among four models but still within reasonable pad printing silicone hardness range. The rubber is soft but has sufficient elasticity, quickly recovers shape after pressing and will not cause pattern deformation. On the contrary, HY-916 ultra soft pad can fully conform to large curved surfaces ensuring complete pattern transfer, with better clarity and completeness than standard hardness pads. Only under excessive pressure or too long pressing time may slight deformation occur, which can be avoided by adjusting printing pressure and speed. HY-916 is the best choice for large curved surface products.

Q: How is the service life of HY-916 pads?

A: HY-916 ultra soft pad service life depends on printing frequency, product shape, ink type, cleaning method and maintenance. Due to lower hardness, wear resistance is slightly less than higher hardness models like HY-902. For regular production, it typically lasts 10000 to 30000 prints. However for large curved and irregular products, standard hardness pads simply cannot print normally, HY-916 is the only viable choice and its service life fully meets production needs for such products. Proper use and maintenance can effectively extend service life, including adjusting appropriate printing pressure, removing residual ink with tape instead of solvent wiping, and wrapping for storage avoiding compression deformation when not in use.

Q: What to do about partial missing pattern when printing large curved products?

A: Partial missing pattern when printing large curved products is mainly caused by pad hardness too high, unable to fully conform to product curved surface, resulting in insufficient local contact. Solutions: First, replace with lower hardness pad like Hongye HY-916 ultra soft model, 16A hardness with elongation ≥400 percent, can fully conform to large curved surfaces. Second, appropriately increase printing pressure to 让 pad deform more fully and conform to product surface, but do not over pressurize to avoid pattern deformation. Third, adjust pad shape, design more conformable pad shape based on product curvature, custom pad mold if necessary. Fourth, check if product has deformation or uneven surface, ensure accurate product positioning. These methods can basically solve partial missing pattern on large curved products.
