Home> Products> Electronic Potting Compound> Electronic Potting Silicone for Security Camera Systems
Electronic Potting Silicone for Security Camera Systems
Electronic Potting Silicone for Security Camera Systems
Electronic Potting Silicone for Security Camera Systems
Electronic Potting Silicone for Security Camera Systems
Electronic Potting Silicone for Security Camera Systems
Electronic Potting Silicone for Security Camera Systems

Electronic Potting Silicone for Security Camera Systems

Get Latest Price
Payment Type:T/T,Paypal
Incoterm:FOB,CFR,CIF,EXW,FAS,FCA,CPT,CIP,DEQ,DDP,DDU,Express Delivery,DAF
Min. Order:1 Kilogram
Transportation:Ocean,Land,Air,Express
Port:shenzhen
Contact Now
Product Description
Product Attributes
Packaging & Delivery
Product Description
Product Attributes

Model No.: HY-9315

Brand: HONG YE SILICONE

Origin: HUIZHOU

Certification: 9001

Packaging & Delivery
Selling Units : Kilogram
Package Type : 1kg/5kg/25kg/200kg
Picture Example :

The file is encrypted. Please fill in the following information to continue accessing it

Inquire the password
electronic potting compound-6
Product Description
HONG YE SILICONE HY‑9315 is a two‑component Thermally Conductive Potting Compound designed for security camera systems. It is a low‑viscosity Addition Curing Silicone with UL94‑V0 flame retardancy, IP65 waterproofing, and excellent thermal conductivity. It cures at room or elevated temperature, provides strong insulation, shock resistance, and wide temperature tolerance from ‑60℃ to 220℃. Ideal for outdoor and indoor security cameras, ensuring stable, long‑term performance in harsh environments.

electronic potting compoundelectronic potting compound


Product Overview

Our Electronic Potting Silicone, also known as Silicone Potting Compound or Electronic Encapsulation Adhesive, is a professional protective material for security camera electronics. As a trusted manufacturer of RTV 2 Silicone Rubber and industrial silicone materials, we deliver a reliable solution for camera modules, PCBs, and IR components. This liquid silicone cures into a soft, elastic layer that protects sensitive circuits from moisture, dust, heat, and impact.

Technical Specifications

HY‑9315 features a 1:1 mix ratio, viscosity 500±100 cps, working time 0.5–2 hours, room‑temperature cure in 4–5 hours. Cured properties: hardness 15±5 Shore A, thermal conductivity ≥0.8 W/(m·K), dielectric strength ≥25 kV/mm, volume resistivity ≥1.0×10¹⁶ Ω·cm, UL94‑V0 flame retardant. Hardness, viscosity, and open time can be customized.

Product Features & Advantages

  • High thermal conductivity for efficient heat dissipation in security cameras.
  • UL94‑V0 flame retardant and RoHS compliant for safe indoor and outdoor use.
  • IP65 waterproof, dustproof, and moisture‑resistant for long‑term outdoor reliability.
  • Wide temperature range ‑60℃ to 220℃, stable in extreme weather.
  • Low viscosity and good flow for potting complex camera components.
  • Soft elastic structure provides excellent shock and vibration resistance.
  • Strong adhesion to PC, PP, ABS, PVC, and metals.

How to Use

  1. Stir Parts A and B separately until fully uniform.
  2. Mix Part A and Part B at a 1:1 weight ratio.
  3. Degas the mixture at 0.08 MPa for 5 minutes if needed.
  4. Pour and cure at room temperature or accelerate with heat.

Application Scenarios

This Silicone Encapsulant is widely used in security camera systems, including outdoor cameras, dome cameras, PCB control boards, IR LED modules, and power supply units. It improves stability, extends service life, reduces failure rates, and lowers maintenance costs for global security equipment manufacturers.

Customization Options

We offer customized formulas: adjustable hardness, viscosity, curing speed, and thermal conductivity. Special formulations for high‑humidity and low‑temperature environments are available to meet diverse project requirements.

Certifications & Compliance

Our product meets EU RoHS, UL94‑V0, and international electrical safety standards. Produced under ISO9001 quality management, ensuring consistent performance for security electronics.

FAQ

Q: Is it suitable for outdoor security cameras?
A: Yes, it is IP65 waterproof, UV‑resistant, and temperature‑stable for long‑term outdoor use.
Q: Can I speed up curing in cold weather?
A: Yes, heating at 80–100℃ for 15 minutes greatly accelerates curing.
Q: Is this silicone reworkable?
A: The soft elastic structure allows gentle component rework and repair.
Q: How long is the shelf life?
A: 12 months below 25℃; non‑hazardous for standard shipping.
