Product Overview
Our Electronic Potting Compound is specially developed for electric scooter controllers, used to encapsulate, seal and fix controller components, power modules and PCB substrates. As a professional supplier of liquid silicone and Thermally Conductive Potting Compound, we provide a reliable alternative to traditionalEpoxy Potting Resin. This flame-retardant formula is tailored for scooter working conditions—resisting vibration, impact, moisture and dust, effectively protecting sensitive electronic components from short circuits and damage, ensuring long-term stable operation of electric scooter controllers. Technical Specifications
This is a two-component addition-curing flame-retardant silicone (model HY-9045 as reference), with customizable parameters. Key properties:
- Mixing ratio (A:B): 1:1 by weight
- Viscosity: 2500±500 Pa.s (liquid state)
- Hardness after curing: 45±5 A°
- Operating time (25℃): 30-60 minutes
- Curing time (80℃): 4-5 hours; room temperature curing available
- Dielectric strength: ≥25 kv/m-1; Volume resistance: ≥1×1015 Ω
- Defoaming: Recommended at 0.08MPa for 3 minutes
- Customizable: Hardness, viscosity and operating time can be adjusted as needed
Product Features & Advantages
- Excellent Flame Retardancy: Forms a reliable flame-retardant system, effectively preventing fire risks caused by controller short circuits, complying with global safety standards for electric vehicles.
- Low Shrinkage & Non-Corrosive: No exotherm or corrosion during curing, avoiding damage to controller chips, soldered joints and PCB substrates, ensuring component integrity.
- Superior Waterproof & Insulation: High sealing performance, preventing moisture, dust and water penetration, ensuring safe operation of controller circuits in various environments.
- Shock & Vibration Resistance: Maintains elasticity in a wide temperature range, absorbing impact and vibration from scooter operation, protecting controllers from road bumps and falls.
- Easy to Use: 1:1 weight mixing ratio, simple operation, supports room temperature or heated curing, adapting to mass production of electric scooters.
- Durable & Stable: Resists chemical media, yellowing and weather aging, ensuring long service life of controllers, reducing after-sales costs.
How to Use (Step-by-Step)
- Pre-Mix Preparation: Fully stir Component A and Component B separately in their respective containers to ensure uniform consistency and avoid sedimentation.
- Component Mixing: Mix Component A and Component B strictly at a 1:1 weight ratio, stirring continuously until homogeneous.
- Vacuum Defoaming: Place the mixed compound in a vacuum container and defoam at 0.08MPa for 3 minutes to remove air bubbles.
- Curing Process: Pour the mixture into electric scooter controller housings; cure at room temperature or heat to accelerate (80℃ for 4-5 hours). Adjust curing speed according to ambient temperature.
Application Scenarios
This Electronic Potting Compound is specifically designed for electric scooter controllers, including power control modules, PCB substrates, and electronic components in scooter control systems. It is also suitable for other electric vehicle control components requiring flame retardancy and waterproofing. For purchasers, it enhances controller safety and stability, reduces failure rates, extends product service life, and lowers maintenance costs, boosting product competitiveness in the global electric scooter market.
Customization Options
We provide full customization for electric scooter controller requirements:
- Adjust curing hardness, viscosity and operating time to match different controller sizes and production processes.
- Optimize flame-retardant, waterproof and thermal conductive performance for extreme working conditions.
- Provide customized formulas beyond the HY-9045 model to meet specific technical needs.
- Support OEM & ODM services and flexible packaging specifications.
Certifications & Compliance
Our Electronic Potting Compound meets international electronic and electric vehicle industry standards, with ISO 9001, CE, RoHS certifications. It has stable batch performance, is non-toxic, environmentally friendly and non-hazardous, widely trusted by global electric scooter manufacturers and component suppliers.
FAQ
Q: Is this potting compound suitable for mass production of electric scooter controllers?
A: Yes. It features a simple 1:1 mixing ratio, easy operation and adjustable curing speed, perfectly adapting to the mass production needs of electric scooter controllers.
Q: What substances should be avoided during use to prevent curing failure?
A: Avoid contact with organotin compounds, sulfur and sulfides, amine compounds, incompletely cured condensation silicone, amine-cured epoxy resin and solder flux, which will affect curing.
Q: How to store unused potting compound?
A: Seal Component A and B separately, store at below 25℃ (shelf life: 1 year). Use mixed compound at one time; stir well if layering occurs, which does not affect performance.
Q: Can it be customized for high-power electric scooter controllers?
A: Yes. We can optimize thermal conductivity and flame-retardant performance to meet the high-temperature and high-power operation requirements of electric scooter controllers.
