Product Overview
Our Electronic Potting for Supercapacitor Cells is a professional Silicone Encapsulant developed specifically for the encapsulation, sealing and protection of supercapacitor cells. As a leading manufacturer of electronic Potting Compound and silicone raw materials, we optimize the formula for the high insulation, low stress and chemical resistance requirements of supercapacitor cells, focusing on insulation, heat resistance, adhesion to electrode/metal and low shrinkage. Compared with ordinary potting compounds, it has better thermal stability, stronger adhesion to supercapacitor electrodes and PCB, and can absorb internal stress caused by high-temperature cycles and charge-discharge processes, effectively protecting supercapacitor cells and pins, reducing failure rates and extending service life for procurement partners.
Key Features & Advantages
- Superior Insulation & High Reliability: Excellent dielectric properties, ultra-strong insulation performance, effectively isolating supercapacitor cells from external electrical interference, preventing short circuits and insulation breakdown, ensuring stable charge-discharge performance and reliable operation, meeting the strict insulation requirements of supercapacitor cells.
- Wide Temperature Adaptability: High temperature resistance (-60℃ to 220℃) and excellent low-temperature performance, can operate stably in extreme temperature environments, absorb internal stress caused by high-temperature cycles and charge-discharge reactions, and protect supercapacitor cells, electrodes and pins from damage or deformation.
- Strong Adhesion & Sealing: Excellent adhesion to supercapacitor cells, electrode materials, PCB, aluminum, copper, stainless steel, PC and PMMA, forming a tight seal, effectively achieving waterproof, moisture-proof, dust-proof and anti-corrosion effects, avoiding moisture intrusion and electrolyte leakage.
- Low Shrinkage & Easy Operation: Two-component liquid design, low curing shrinkage, no damage to delicate supercapacitor cells and electrodes; simple mixing ratio, easy to stir evenly; supports room temperature or heat curing, full curing in 24 hours, optional vacuum degassing, improving production efficiency for batch production of supercapacitors.
- High Stability & Environmental Protection: Low volatility, high strength, no harmful substances, complying with EU RoHS and international environmental standards; no stratification or performance degradation after long-term storage, compatible with supercapacitor electrolyte and electrode materials, ensuring consistent product quality.
How to Use (Step-by-Step Guide)
- Pre-Mixing Preparation: Fully stir Component A to mix the settled filler evenly, and shake Component B thoroughly to ensure uniform consistency, avoiding affecting the curing effect and adhesion to supercapacitor cells and electrode materials.
- Mixing: Mix Component A and Component B according to the specified weight ratio (customizable), stir slowly and evenly to avoid generating air bubbles, which will affect the insulation and sealing performance, and prevent damage to delicate supercapacitor cells.
- Degassing (Optional): Put the mixed potting compound into a vacuum container, degas at 0.01MPa for 3 minutes to completely eliminate air bubbles, then it can be used for pouring.
- Curing: Pour the degassed potting compound into the supercapacitor cell packaging mold, place it at room temperature for curing or heat to accelerate curing; after basic curing, proceed to the next process, and full curing takes 24 hours. Note: Environment temperature and humidity significantly affect curing speed.
Application Scenarios
This specialized electronic potting compound is mainly used for the encapsulation, sealing, filling and pressure protection of supercapacitor cells. It is widely applied in high-precision electronic devices, including energy storage equipment, automotive electronics, industrial control devices, communication equipment, emergency power supplies and consumer electronics. It provides reliable insulation, heat dissipation and protection for supercapacitor cells, reducing failure rates caused by moisture, dust, corrosion and electrolyte leakage, improving product stability, and helping procurement partners reduce production costs and enhance product competitiveness.
Technical Specifications
Type: Addition-Curing Silicone; Mix Ratio (A:B): Customizable (weight ratio); Appearance: Liquid (both components); Viscosity: Customizable (suitable for supercapacitor cell encapsulation); Hardness (Shore A): Customizable; Operating Temperature: -60℃ to 220℃; Dielectric Strength: ≥25 kV/mm; Volume Resistivity: ≥1.0×10¹⁶ Ω·cm; Adhesion: Excellent (electrode materials, aluminum, PCB, metal); Volatility: Minimal; Curing Time: 24 hours (room temperature, heat-accelerated optional); Degassing Condition: 0.01MPa for 3 minutes; Compliance: EU RoHS; Shelf Life: 12 months (sealed storage); Customizable models available.
Certifications & Compliance
Our Electronic Potting for Supercapacitor Cells complies with international electronic, safety and environmental protection standards: ISO 9001 (strict quality control), CE Certification, EU RoHS Directive, meeting global supercapacitor production requirements, trusted by global electronic component manufacturers and procurement partners.
Customization Options
We provide supercapacitor cell-specific tailored solutions: custom formulations (adjust viscosity, hardness, curing speed, insulation and thermal conductivity), adhesion optimization for supercapacitor electrodes and cells, and flexible parameter adjustment, meeting small-batch customization and large-scale production needs of different electronic industries, adapting to various supercapacitor cell specifications.
Production Process & Quality Control
We implement a 5-step strict quality control process: high-purity silicone raw materials screening, precision automated formulation mixing, performance testing (insulation, adhesion to electrodes, temperature resistance), curing verification, and sealed packaging. Our monthly capacity exceeds 500 tons, supporting stable supply for global orders. The product is non-hazardous, transportable as general chemicals, and has a 12-month shelf life when sealed and stored properly.
FAQ
Q: Is it suitable for all types of supercapacitor cells?
A: Yes, it can be customized to match different supercapacitor cell specifications, with good compatibility and adhesion to electrode materials.
Q: What’s the mixing ratio?
A: Customizable weight ratio, easy to operate and adjust.
Q: Will it damage delicate supercapacitor cells or affect charge-discharge performance?
A: No, it has low shrinkage and no exotherm during curing, compatible with electrolytes, avoiding damage and performance impact.
Q: What’s the curing time?
A: 24 hours at room temperature, heat-accelerated optional.
Q: Shelf life?
A: 12 months when sealed and stored properly, stratification does not affect performance after stirring.
