HY-912 Multi Color Eco Friendly Pad Printing Silicone RoHS REACH Certified for Export Toys Gifts Electronics

Hongye HY-912 is a multi color eco friendly general purpose two component RTV Pad Printing Silicone developed by Shenzhen Hongyejie Technology Co., Ltd. for export enterprises. With 25±2 Shore A hardness, it is the general purpose golden hardness among four models, suitable for both flat and slightly curved surface printing, with tensile strength ≥3.5MPa, tear strength ≥15kN/m and elongation ≥350%, providing balanced and stable performance.

Export enterprises have strict requirements for product eco certification. European and American markets mandate RoHS and REACH compliance, and also require high color consistency and batch stability for pads. HY-912 eco model specifically meets these needs, passing RoHS and REACH testing and certification. Multiple colors available including red, yellow, white and green four standard colors. Mature formula with stable batch quality ensures consistent quality for long term supply. General purpose hardness has wide application range, can print both hard flat products and slightly curved surfaces, making it the preferred model for export enterprises. Working time 30 to 45 minutes, slightly longer than other models, giving operators more ample time, suitable for manual dispensing and small batch multi variety production. Standard 100:2 mixing ratio, easy operation.

Key Features

• RoHS and REACH certified, meeting European and American export requirements

• 25±2 Shore A hardness, general purpose golden hardness for flat and curved surfaces

• Multiple colors available, red yellow white green four standard colors

• Mature formula with stable batch quality, consistent long term supply

• Tensile strength ≥3.5MPa, tear strength ≥15kN/m, balanced performance

• Working time 30 to 45 minutes, more ample for manual dispensing

• Uniform ink pickup and transfer, sharp clear patterns

• Standard 100:2 mixing ratio, easy operation

Technical Specifications

表格

Model Color Hardness A Viscosity mPa.s Time min Cure h Tensile MPa Tear kN/m Elong % Ratio Density

HY-912 R/Y/W/G 25±2 13000 30-45 2-4 ≥3.5 ≥15 ≥350 100:2 1.13

HY-902 R/Y/W/G 28±2 15000 30-40 2-4 ≥4.0 ≥18 ≥320 100:2 1.15

HY-901 R/Y/W/G 23±2 12000 30-40 2-4 ≥3.0 ≥12 ≥300 100:2 1.12

HY-916 R/Y/W/G 16±2 10000 30-40 2-4 ≥2.5 ≥10 ≥400 100:2 1.10

Note: Above are typical values, actual parameters subject to each batch COA report. Test conditions: temperature 25±2°C, relative humidity 50±5%.

Application Scenarios

Export Toys and Gifts Printing

Export toys and gifts industry includes plastic toys, figurines, educational toys, craft gifts, promotional gifts etc., mostly exported to Europe, America and Japan, with strict eco certification requirements, must pass RoHS and REACH testing. Toys and gifts have various shapes, both flat and slightly curved surfaces, requiring high pad versatility.

Hongye HY-912 multi color eco friendly general purpose Pad Printing Silicone is specially designed for export toys and gifts industry. RoHS and REACH certified, meeting European and American market access requirements. 25A general purpose golden hardness can print flat logos and also handle slightly curved surfaces like figurine faces, one pad type for multiple products, reducing inventory and changeover cost. Multiple colors available. Stable batch quality suitable for export enterprises mass stable production.

Export Electronics and Stationery Printing

Export electronics and stationery industry includes remote controls, buttons, calculators, mouse housings, pens, rulers, erasers, pencil cases etc., exported worldwide, with high requirements for eco certification and printing quality. Electronic products usually have flat and slightly curved surfaces with high printing precision requirements. Stationery products have large production volume requiring pad stability and long life.

Hongye HY-912 eco friendly general purpose pad printing silicone performs excellently in export electronics and stationery industry. RoHS and REACH certified, complying with international eco standards. General purpose hardness has wide application range, printing sharp clear patterns on flat products and good conformability on cylindrical or slightly curved products. Uniform ink pickup and transfer, fine patterns transfer clearly with sharp edges. Working time 30 to 45 minutes gives operators more ample dispensing time, suitable for small batch multi variety production.

Operating Instructions

Step 1 Pad Mold Preparation: Thoroughly clean the pad mold, wipe with alcohol and apply mold release agent evenly, leave 5 to 10 minutes to dry. Place mold on a level stable surface.

Step 2 Component A Preparation: Stir component A base rubber thoroughly for 1 to 2 minutes before pouring to ensure uniform color and filler distribution, scrape bucket walls and bottom.

Step 3 Weighing and Mixing: Accurately weigh A and B at 100:2 ratio by weight using electronic scale, within ±5 percent tolerance. Mix thoroughly for 3 to 5 minutes, scraping container walls and bottom.

Step 4 Pouring and Degassing: Slowly pour mixed silicone from one side of the mold, let it flow naturally to fill. Fill to about 80 percent. Use vacuum at negative 0.09MPa for 2 to 3 minutes if available, or let sit 5 to 10 minutes.

Step 5 Curing and Demolding: Cure at room temperature 25°C for 2 to 4 hours. For faster curing, heat at 60°C for 30 to 60 minutes, temperature not exceeding 100°C. Gently remove the pad, let rest 24 hours before use.

Step 6 Usage and Maintenance: Wipe pad surface with alcohol before use. Do several test prints first to condition the surface. Gently remove residual ink with clean nonwoven cloth or tape. Wrap with plastic film when not in use.

Selection Guide

HY-901 Economy 23A for beginners, small batch, sampling and regular production.

HY-902 High Wear 28A for mass continuous production, high frequency pressing, hard flat printing.

HY-912 Eco Friendly 25A for export toys, gifts, electronics, stationery requiring eco certification.

HY-916 Ultra Soft 16A for large curved surfaces, spherical, humanoid, animal shaped toys.

Recommended Application

General purpose eco friendly pad printing head for export toys gifts electronics stationery

Quality and Compliance

Each batch produced under ISO 9001 certified quality management system. Tested for viscosity, mixing ratio, curing time, hardness, tensile, tear, elongation, color and density before shipment. Each batch comes with COA report. HY-912 passes RoHS 2.0 and REACH SVHC testing, third party test report available. Hongye Silicone since 2005, 20000 square meter factory, 500+ tons monthly, supplied to 60+ countries. Shelf life 12 months sealed below 25°C.

Packaging Specifications

Standard packaging includes 1kg trial kit, 5kg kit, 20kg bucket, 25kg bucket and 200kg drum. Components A and B packed separately. Custom packaging and OEM service available for orders above 200kg. Each package labeled with product name, model, batch number, production date, expiry date, mixing ratio, net weight and safety information.

Competitive Advantages

Own silicone polymer synthesis and compounding production lines, fully controlling raw material quality and batch consistency. 20000 square meter Shenzhen factory, 500+ tons monthly, prices 30 to 50 percent lower than imported premium with comparable performance. HY-912 eco model RoHS and REACH certified. Standard models in stock 3 to 5 working day delivery. Technical sales engineers provide on site trial production, mold design review and custom formulation. OEM customers enjoy private label, neutral packaging, multilingual COA and exclusive batch traceability.

Ordering and Logistics

Contact sales with model, quantity, color, destination country and shipping method. Accept T/T, PayPal for sample orders and Alibaba trade assurance. 1kg trial kit available. Standard packaging shipped 3 to 5 working days after payment. DHL, FedEx, UPS worldwide, sea freight for bulk. Non hazardous under most shipping regulations. Each shipment comes with commercial invoice, packing list, COA, SDS and RoHS REACH test report.

Technical Support and Custom Service

Dedicated technical service team average 10+ years experience. Full lifecycle support including model selection, on site or remote trial production, mold design review, printing parameter optimization, failure analysis. Custom formulations including hardness adjustment, Pantone color matching, curing speed adjustment, special eco certification. Custom development 7 to 14 working days from confirmation to sample shipment.

Precautions

Use polyethylene, nylon or nitrile gloves, do not use natural latex gloves. Avoid contact with sulfur containing substances, amines, phosphorus compounds, tin cure silicone and PVC. Use calibrated scale for accurate 100:2 weighing, mix thoroughly 3 to 5 minutes. Heat curing temperature not exceeding 100°C. Maintain good ventilation. Component B has mild irritation, avoid direct contact with skin and eyes. Seal containers immediately after use.

Storage

Store in sealed containers below 25°C in dry ventilated area, avoid direct sunlight, keep away from sulfur containing substances, amines, food and strong chemicals. Shelf life 12 months from production date. Seal immediately after taking material. Refrigeration at 5 to 15°C extends shelf life, warm to room temperature before opening. Store components A and B separately.

FAQ

Q: Can you provide RoHS and REACH certificate report for HY-912?

A: Yes. HY-912 passes RoHS 2.0 and REACH SVHC testing. Each shipment can include third party test report copy. Report covers lead, mercury, cadmium, hexavalent chromium, PBB, PBDE and REACH SVHC substances. Export enterprises can use for customs clearance and customer audit. For special certification like UL, FDA, contact technical support for custom formulation.

Q: What is the difference between HY-912 and HY-901?

A: HY-912 is multi color eco friendly general purpose 25A, RoHS and REACH certified, multiple colors, stable batch, working time 30 to 45 minutes, ideal for export enterprises. HY-901 is economy 23A, more affordable, easy operation, ideal for domestic sales, small batch, sampling and cost sensitive enterprises. Export requiring eco certification choose HY-912, domestic no certification needed choose HY-901. Both suitable for flat and slightly curved products.

Q: What colors does HY-912 have? Can custom color be made?

A: HY-912 standard colors include red, yellow, white and green. Choose based on product color, ink type and preference. Light ink uses dark pad, dark ink uses light pad for easy observation. Other colors like blue, black, orange available via custom Pantone matching. Custom MOQ 20kg, delivery 7 to 10 working days. Custom color becomes exclusive formula in subsequent orders.
