Product Overview
Our Transformer Electronic Potting Silicone Compound is a professional potting material tailored for transformer electronic protection, a key part of HONG YE SILICONE’s full silicone product matrix. Model HY-9055 is a new type of thermal conductive insulation silicone synthesized from organics, designed to solve transformer pain points—heat accumulation, high-voltage breakdown and electromagnetic interference. It is liquid before mixing (Component A: dark gray fluid; Component B: white fluid), cures into a low-shrinkage, dense protective layer, forming a reliable thermal conductive insulation system to ensure stable, safe operation of transformers, far exceeding ordinary Electronic Potting Compound in transformer application adaptability. Product Features & Advantages
1. Transformer-specific thermal conductivity: Thermal conductivity ≥0.8 W/(m·k), efficiently dissipates heat generated by transformer windings during operation, reduces insulation aging caused by heat accumulation, extends transformer service life and reduces failure rates.
2. Superior high-voltage insulation: Volume resistivity ≥1.0×10¹⁶ Ω·cm, dielectric strength ≥25 kv/mm, effectively resisting high-voltage breakdown, ensuring safe operation of transformer electronic components and avoiding short circuits.
3. Gentle curing & production-friendly: Cures at room temperature with fast speed (4-5h at 25℃, 20min at 80℃), no exotherm or corrosion to fragile transformer windings; low winter temperatures can be solved by proper heating, adapting to automated transformer production lines.
4. All-round transformer protection: Combines waterproof, moisture-proof, mold-proof and dust-proof properties, with excellent anti-electromagnetic interference, chemical medium resistance and weather aging resistance, adapting to harsh transformer working conditions.
5. Easy operation & high compatibility: 1:1 weight mixing ratio (easy to measure), good fluidity; optional deaeration at 0.08MPa for 3 minutes ensures bubble-free potting, firmly fixing transformer components without loosening due to temperature changes.
Technical Specifications (Model HY-9055)
This product is a two-component transformer protection potting silicone: Component A is dark gray fluid, Component B is white fluid, with dynamic viscosity of 3000±500 mPa·s. The mixing ratio is 1:1 by weight; operable time is 30-60 minutes at 25℃, curing time is 4-5 hours at 25℃ or 20 minutes at 80℃. After curing, it reaches Shore A hardness 55±5, linear expansion coefficient ≤2.2×10⁻⁴ m/(m·k), thermal conductivity ≥0.8 W/(m·k), dielectric strength ≥25 kv/mm, dielectric constant 3.0-3.3 (1.2MHz), volume resistivity ≥1.0×10¹⁶ Ω·cm, UL94-V1 flame retardancy. Other models and customizable parameters are available on request.
How to Use
1. Preparation: Fully stir Component A and B separately in their respective containers to ensure uniform material composition without stratification, critical for stable thermal conductivity and high-voltage insulation performance.
2. Mixing: Blend Component A and B strictly according to 1:1 weight ratio, stir thoroughly to guarantee consistent thermal conductivity, insulation and curing performance for transformer components.
3. Deaeration (Optional): After mixing evenly, place the glue into a vacuum container and deaerate for 3 minutes under 0.08MPa to remove air bubbles, avoiding heat accumulation and high-voltage breakdown caused by bubbles.
4. Potting & Curing: Pour the treated silicone onto transformer electronic components (windings, circuits); cure at room temperature or heat to accelerate (80℃ for 20 minutes). In low winter temperatures, proper heating can accelerate vulcanization to match transformer mass production rhythm.
Application Scenarios
Widely used for potting, sealing and fixing of transformer electronic components requiring thermal conductivity, high-voltage insulation and waterproofing, including power transformers, distribution transformers, electronic transformers, transformer power modules and control modules. It is also suitable for LED junction boxes, wind turbine electronic components and circuit boards, providing all-round protection in transformer manufacturing, power equipment and new energy industries, reducing transformer failure rates, extending service life and lowering after-sales costs.
Certifications and Compliance
HONG YE SILICONE holds ISO9001 quality management system certification, CE and UL certifications. Our Transformer Electronic Potting Silicone Compound (HY-9055) fully complies with EU ROHS environmental directives, UL94-V1 flame retardant standards and international transformer electronic material standards, meeting the quality and safety requirements of global transformer markets, facilitating smooth import and reliable application in international power projects.
Customization Options
We provide professional OEM customization services focused on transformer protection needs. According to customers’ transformer types (power, distribution) and working environments, we can customize key parameters such as cured hardness, viscosity, operable time, curing speed and thermal conductivity, optimizing heat dissipation and high-voltage insulation to meet personalized bulk procurement needs of transformer manufacturers.
Production Process
The product undergoes strict multi-link quality control: high-quality thermal conductive Silicone raw materials inspection → precise formula mixing (optimized for transformer heat dissipation and high-voltage insulation) → automated production and filling → pre-production sample performance testing (targeting transformer working scenarios) → full inspection of finished products before shipment. Our professional QC team monitors the whole process, ensuring consistent transformer protection performance of each batch. FAQ
Q1: What packaging specifications are available? A1: 5kg, 20kg, 25kg and 200kg, suitable for small-batch transformer sample testing and large-batch mass production.
Q2: How to store unused potting silicone? A2: Seal and store Component A and B separately in a cool, dry place; mixed glue should be used up at one time; stratified colloid can be stirred evenly before use, no impact on transformer protection performance.
Q3: Is it suitable for high-voltage power transformers? A3: Yes, it has excellent high-voltage insulation (dielectric strength ≥25 kv/mm), efficiently resists breakdown, protecting core transformer components from high-voltage damage.
Q4: Is it a hazardous material for transportation? A4: Non-hazardous, can be transported as general chemicals, complying with international transportation standards for transformer production materials.
Q5: Can it reduce transformer heat accumulation effectively? A5: Yes, it has excellent thermal conductivity (≥0.8 W/(m·k)), quickly dissipates heat from transformer windings, slowing down insulation aging and extending transformer service life.
