HONG YE SILICONE Control Board Electronic Potting Silicone Compound (Model HY-9315) is a high-performance two-component addition-curing thermal conductive potting material, specially engineered for control board protection. Mixed at 1:1 weight ratio, it features UL94-V0 flame retardancy, IP65 waterproof rating, excellent thermal conductivity (≥0.8 W(m·K)) and high insulation. As a core product matching our liquid silicone, RTV 2 Silicone Rubber, Industrial mold silicone rubber, Pad Printing Silicone and Silicone Encapsulant, it protects control boards from moisture, dust and impact, ensures stable operation (-60℃ to 220℃), meets EU ROHS, with 1-year shelf life, customizable parameters and multiple packaging options for bulk control board production.
Product Overview
Our Control Board Electronic Potting Silicone Compound is a professional low-viscosity, flame-retardant two-component addition-curing organic silicone potting material, a key part of HONG YE SILICONE’s full silicone product matrix. Model HY-9315 is tailored for control board protection, designed to solve control board pain points—heat accumulation, signal interference, moisture damage and component loosening. It can cure at room temperature or with heating (faster at higher temperatures), forming a soft rubber-like protective layer, providing comprehensive insulation, waterproofing and fixation for control boards, far exceeding ordinary Electronic Potting Compound in control board adaptability. Product Features & Advantages
1. Control board-specific precise导热: Thermal conductivity ≥0.8 W(m·K), efficiently dissipates heat from control board chips and components, avoids overheating-induced malfunctions, ensuring stable and accurate control signals.
2. Superior safety performance: UL94-V0 flame retardancy (highest level for control boards), IP65 waterproof rating, and high insulation (volume resistivity ≥1.0×10¹⁶ Ω·cm, dielectric strength ≥25 kv/mm), eliminating fire and short-circuit risks.
3. Wide temperature adaptability & anti-impact: Operates stably from -60℃ to 220℃, adapts to various working environments; cures into soft rubber, with excellent impact resistance, protecting fragile control board components from collision damage.
4. Easy operation & production-friendly: 1:1 weight mixing ratio (easy to measure), low viscosity and good leveling; optional deaeration at 0.08MPa for 5 minutes ensures bubble-free potting, suitable for automated control board production lines.
5. Strong compatibility & customization: Adheres well to PC, PP, ABS, PVC and metals, compatible with all types of control board substrates; hardness, viscosity and operable time can be customized to match different control board sizes and processes.
Technical Specifications (Model HY-9315)
This product is a two-component control board potting silicone: Component A and B are both liquid, each with a viscosity of 500±100 cps. Mixing ratio is 1:1 by weight, mixed viscosity 500±100 cps, operable time 0.5-2 hours. Curing time is 4-5 hours at room temperature or 20 minutes at 80℃. After curing, it reaches Shore A hardness 15±5, thermal conductivity ≥0.8 W(m·K), dielectric strength ≥25 kv/mm, dielectric constant 3.0～3.3 (1.2MHz), volume resistivity ≥1.0×10¹⁶ Ω·cm, linear expansion coefficient ≤2.2×10⁻⁴ m/(m·K), UL94-V0 flame retardancy. Other models and customizable parameters are available on request.
How to Use
1. Preparation: Fully stir Component A and B separately in their respective containers to ensure uniform material composition, critical for stable thermal conductivity and insulation performance of control boards.
2. Mixing: Blend Component A and B strictly according to 1:1 weight ratio, stir thoroughly to guarantee consistent curing and protective performance for control board components.
3. Deaeration (Optional): After mixing evenly, place the mixed liquid into a vacuum container and deaerate for 5 minutes under 0.08MPa to remove air bubbles, avoiding heat accumulation and signal interference caused by bubbles.
4. Potting & Curing: Pour the treated silicone onto control boards; cure at room temperature (8 hours) or heat (80～100℃ for 15 minutes, recommended in winter). For thick application, extend curing time appropriately.
Application Scenarios
Widely used for potting, insulation, waterproofing and fixation of various control boards and their components, including washing machine control boards, pulse igniters, electric bicycle drive controllers, power module control boards, electronic module control boards and outdoor display control boards. It is also suitable for mold pressing of complex electronic accessories, applied in home appliances, automotive electronics, industrial control and LED industries. It extends control board service life, reduces malfunction rates and after-sales costs, enhancing product quality for control board manufacturers.
Certifications and Compliance
HONG YE SILICONE holds ISO9001 quality management system certification, CE and UL certifications. Our Control Board Electronic Potting Silicone Compound (HY-9315) fully complies with EU ROHS environmental directives, UL94-V0 flame retardant standards and international electronic control board material standards, meeting global control board market requirements, facilitating smooth import and reliable application in international projects.
Customization Options
We provide professional OEM customization services focused on control board needs. According to customers’ control board types (home appliance, industrial) and application scenarios, we can customize key parameters such as cured hardness, viscosity, operable time and curing speed, optimizing thermal conductivity and insulation to meet personalized bulk procurement needs.
Production Process
The product undergoes strict multi-link quality control: high-quality thermal conductive Silicone raw materials inspection → precise formula mixing (optimized for control board heat dissipation) → automated production and filling → pre-production sample performance testing → full inspection of finished products before shipment. Our QC team monitors the whole process, ensuring consistent protection performance of each batch. FAQ
Q1: What packaging specifications are available? A1: 5kg, 20kg, 25kg and 200kg, suitable for small-batch control board testing and large-batch mass production.
Q2: What is the shelf life and storage method? A2: 1-year shelf life under 25℃; store in sealed containers in a cool, dry place; non-hazardous, transportable as general chemicals.
Q3: Is it suitable for thick control board potting? A3: Yes, but curing time needs to be extended appropriately; heating curing is recommended to ensure full curing and optimal performance.
Q4: Can it be used for home appliance control boards? A4: Yes, it is widely applied to washing machine control boards, pulse igniters, etc., with IP65 waterproof and UL94-V0 flame retardancy, ensuring safe operation.
Q5: How to speed up curing in winter? A5: Heat curing at 80～100℃ for 15 minutes, which effectively shortens curing time and ensures stable performance of control board potting.
